Maung Aluminium stands out as a top-notch manufacturer and supplier located in Naypyidaw, Myanmar, with a focus on high-quality aluminium products like **Aluminium 7075 Chequered Plates**. The company expertly blends cutting-edge production technology with rigorous quality control to provide materials that are not only durable and lightweight but also resistant to corrosion, making them perfect for tough industrial uses. With a strong commitment to precision, sustainability, and keeping customers happy, Maung Aluminium has built a solid reputation both in Myanmar and beyond. Their **7075 Chequered Plates** are popular in the aerospace, construction, and transportation industries, thanks to their impressive strength and reliability.
The **Aluminium 7075 Chequered Plates** are primarily made of aluminium, with zinc being the key alloying element, along with magnesium, copper, and chromium. This particular alloy is celebrated for its outstanding strength-to-weight ratio and toughness. The plates boast excellent fatigue resistance, good machinability, and moderate corrosion resistance, especially when anodized. Their mechanical properties include high tensile and yield strength, making them perfect for applications that require top-notch structural performance. Even though they are lightweight, these plates can handle heavy loads and tough environments with ease.
Standards : ASTM B209 / ASME SB209
Temper : T3, T4, T5, T6, T651, T6511
Thickness : 0.2-300
Width : 100-2600
Length : 500-10000
Surface : Bright, polished, hair line, brush, sand blast, embossed, etching, etc.
Finish :Mill, Customer specific finish
Aluminum Chequered Plate Coating : PVC Coated, Color Coated, Polyester, Fluorocarbon, polyurethane and epoxy coating
Type : Hot-Rolled (HR) / Cold-Rolled (CR) Chequered Plate
| UNS | EN | DIN,WNr | JIS | AFNOR | ISO | BS | GOST |
| A97075 | ENAW-AlZn5.5MgCu EN AW-7075 | 3.4365 AlZnMgCu1.5 | 7075 | 7075 A-Z5GU | AlZn6MgCu | 7075 L95 L96 | V95 |
| Weight % | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Each | Total |
| Minimum | 1.20 | 2.10 | 0.18 | 5.10 | ||||||
| Maximum | 0.40 | 0.50 | 2.00 | 0.30 | 2.90 | 0.28 | 6.10 | 0.20 | 0.05 | 0.15 |
| Temper | Tensile | Hardness | ||||
| Ultimate | Yield | Elongation | Brinell | |||
| KSI | MPA | KSI | MPA | % | ||
| T6, T651 | 83 | 572 | 73 | 503 | 11 | 150 |
| T73, T7351 | 73 | 503 | 63 | 434 | 13 | N/A |
Maung Aluminium based in Naypyidaw, Myanmar is a renowned manufacturer and supplier of premium aluminium products, including Aluminium Bars, Sheets and Plates, Coils, Chequered Plates, Wires, Pipes, Fittings, Flanges, Forging, Circle, Angles. With a commitment to delivering exceptional quality and service, we cater to diverse industries, offering reliable solutions tailored to specific requirements. Our products are known for their superior strength, corrosion resistance, and precise dimensions. We focus on customer satisfaction by providing an extensive range of aluminium bars designed for structural, industrial, and decorative applications.
Yes, we offer custom sizes for Aluminium 7075 Chequered Plates to meet specific project needs. Our team at Maung Aluminium is committed to providing customized solutions for all your requirements. For more details, contact us at sales@maungaluminium.com
In industries that require high strength and durability, **Aluminium 7075 Chequered Plates** are widely used. In aerospace, they find their place in aircraft fittings, wings, and structural components. The automotive and marine industries utilize them for flooring, tread plates, and protective coverings, thanks to their anti-slip surface. In construction, they are used as sturdy walkways, platforms, and stair treads, providing both functionality and a sleek look. Moreover, their unique combination of strength, lightness, and resistance to corrosion makes them ideal for tooling, molds, and high-stress industrial equipment.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
