Maung Aluminium is a well-respected manufacturer and supplier located in Naypyidaw, Myanmar, known for its top-notch Aluminium 2024 Flat Bars. These bars are prized for their remarkable strength, outstanding fatigue resistance, and excellent machinability, making them perfect for high-performance engineering and structural projects. Maung Aluminium is committed to precision manufacturing and follows international standards, ensuring that their Aluminium 2024 Flat Bars provide exceptional mechanical performance and reliability. With a strong emphasis on quality and consistency, the company serves industries like aerospace, automotive, and mechanical engineering, which require materials that are durable, lightweight, and high-strength.
Aluminium 2024 Flat Bars mainly consist of aluminium and copper (3.8–4.9%), along with small amounts of magnesium, manganese, and silicon. This copper-rich alloy boasts a tensile strength of around 470–520 MPa, excellent fatigue resistance, and good machinability. While its corrosion resistance is moderate, it can be significantly enhanced through anodizing or cladding. Additionally, the alloy provides good thermal and electrical conductivity, making it suitable for applications that require a blend of strength, formability, and precision.
Specification : ASTM B 221 ASME SB 221, B211, B565, B316 1100, AMS 4102
Standard : ASTM, BS and all International Standards
Temper : O, H12, H14, H16, H18, H22, H24, H26, H32, H112
Length : 100 mm To 3000 mm Long & Above
Size : 5 mm To 500 mm
| Aluminium 2024 | Fe | Si | Mg | Mn | Cu | Zn | Ti | Al |
| 0.50 | 0.50 | 1.20 – 1.80 | 0.30 – 0.90 | 3.8 – 4.9 | 0.25 | 0.15 | 93.5 |
| Typical Mechanical Properties (Min) | |||
| Diameter or minor sectional dimension mm | Tensile Strength, MPa | Yield Strength 0.2%, MPa | Elongation % |
| 0-12.7 | 427 | 310 | 10 |
| 12.7-114.30 | 427 | 290 | 10 |
| 114.30-165.1 | 427 | 276 | 10 |
| 165.1-203.2 | 400 | 262 | 10 |
| STANDARD | UNS | WERKSTOFF NR. | European Standard | BS (OLD) | ISO | USA (AA) | GERMANY (DIN) |
| Aluminium 2024 | A92024 | 3.1355 | AW-AlCu4Mg1 | AU4G1 | AlCu4Mg1 | 2024 | AlCuMg2 |
Maung Aluminium based in Naypyidaw, Myanmar is a renowned manufacturer and supplier of premium aluminium products, including Aluminium Bars, Sheets and Plates, Coils, Chequered Plates, Wires, Pipes, Fittings, Flanges, Forging, Circle, Angles. With a commitment to delivering exceptional quality and service, we cater to diverse industries, offering reliable solutions tailored to specific requirements. Our products are known for their superior strength, corrosion resistance, and precise dimensions. We focus on customer satisfaction by providing an extensive range of aluminium bars designed for structural, industrial, and decorative applications.
Yes, we offer custom sizes for Aluminum 2024 Flat Bars to meet specific project needs. Our team at Maung Aluminium is committed to providing customized solutions for all your requirements. For more details, contact us at sales@maungaluminium.com
Aluminium 2024 Flat Bars find extensive use in the aerospace, automotive, and defense sectors. They are particularly well-suited for crafting aircraft structures, fuselage panels, and wing components due to their impressive strength-to-weight ratio. In the automotive realm, they are utilized in suspension systems, chassis frames, and engine components. These bars are also ideal for marine, structural, and mechanical applications, including brackets, machine parts, and load-bearing assemblies, where superior strength, durability, and long-term reliability are essential.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
