Maung Aluminium, based in Naypyidaw, Myanmar, is a reputed manufacturer and supplier of Aluminium 1050 Forgings, known for their excellent purity, durability, and corrosion resistance. The company specializes in producing high-quality forgings that meet international standards, ensuring reliable performance in various industrial applications. With a focus on precision engineering and customer satisfaction, Maung Aluminium delivers products that combine strength with excellent workability. Aluminium 1050 Forgings are widely appreciated for their smooth surface finish, light weight, and superior conductivity, making them ideal for electrical, chemical, and architectural industries.
Aluminium 1050 Forgings are composed of 99.5% pure aluminium, with minimal additions of silicon, iron, and other trace elements. This composition provides excellent corrosion resistance, high electrical and thermal conductivity, and outstanding ductility. These forgings possess a tensile strength of about 60–95 MPa and a yield strength near 30 MPa, ensuring flexibility and ease of fabrication. They can be cold worked to improve hardness without losing their formability. The material’s non-heat-treatable nature and high reflectivity make it ideal for applications requiring both strength and appearance.
Standards : ASTM B247, B247
Temper : H14
Specification : DIN, ASTM, BS and all International Standards
Flat bar blocks : up to 27″ width and 15,000 lbs.
Cylinders and sleeves : up to 50″ maximum O.D. and 65″ maximum length
Discs and hubs : up to 50″ diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged rings : up to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shafts : up to 144″ maximum length and 20,000 lbs.
| European Standard | BS (OLD) | USA (AA) | GERMANY (DIN) | ISO | IS | Canadian |
|---|---|---|---|---|---|---|
| EN AW-1050 A | 1E | 1050 | Al99.5 | Al99.5 | 19500, 19501 | 1 S |
| Alloy (ISS) | Equivalent alloy (A.A) | Copper | Magnesium | Silicon | Iron | Managanese Others* (Total) | Remarks | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Old | New | U.S.A | Min. | Max. | Min. | Max. | Min. | Max. | Min. | Max. | Max | Max. | Aluminum 99.0% Min. | ||
| 1 B | 19500 | 1050 | — | 0.05 | — | — | — | 0.30 | 0.4 | — | 0.05 | 0.1 | Aluminum 99.5% Min. | ||
| Alloy | Temper | UTS (Mpa) | Yield Strength (Mpa) | Elongation (%) | ||
|---|---|---|---|---|---|---|
| Minimum | Maximum | Minimum | Maximum | A 50mm (Minimum) | ||
| EN AW-1050 A | F | 60 | – | 20 | – | 23 |
| O | 60 | 95 | 20 | – | 23 | |
Aluminium 1050 Forgings are made up of 99.5% pure aluminium, with a few additions of iron, silicon, copper, and manganese to boost strength and formability. These forgings are known for their excellent corrosion resistance, as well as their thermal and electrical conductivity, and reflectivity. They have mechanical properties that include a tensile strength ranging from 60 to 100 MPa and a yield strength between 20 and 40 MPa, along with impressive elongation and ductility. Their soft temper makes them easy to shape, machine, and polish, which is perfect for creating intricate and decorative forged components.
Yes, we offer custom sizes for Aluminium 1050 Forgings to meet specific project needs. Our team at Maung Aluminium is committed to providing customized solutions for all your requirements. For more details, contact us at sales@maungaluminium.com
Aluminium 1050 Forgings are extensively used in the electrical, chemical, and food processing industries due to their excellent corrosion resistance and conductivity. They are commonly used in manufacturing components like reflectors, heat exchangers, and decorative panels. In the construction and automotive sectors, they are preferred for lightweight structural parts. These forgings are also suitable for equipment in marine and chemical environments because of their ability to resist oxidation. Their versatility, smooth surface finish, and cost-effectiveness make Aluminium 1050 Forgings a popular choice for numerous industrial and commercial applications.
